How Do You Choose The Right Through Bore Rotary Union Size?

Selecting the correct size of a Through Bore Rotary Union is essential for ensuring efficient fluid transfer, system safety, and long service life in industrial equipment. These components are widely used in CNC machinery, hydraulic systems, packaging machines, and automation equipment where continuous rotation and fluid or gas transfer are required.

A rotary union through bore is designed with a central hollow shaft that allows cables, pipes, or shafts to pass through the center while transferring media such as water, oil, air, or coolant. When choosing the right size, the first and most important factor is the diameter of the shaft or passage that needs to go through the rotary system. The inner bore must be large enough to accommodate the application requirements without causing friction or obstruction.

Another key consideration is the operating pressure and flow rate of the system. A hollow shaft Rotary Union must be selected based on the volume and pressure of the fluid being transferred. Higher pressure applications require stronger sealing structures and more durable materials to prevent leakage and ensure stable performance over time.

The type of media being transferred also plays an important role. A rotary joint through bore used for water cooling systems may have different material and sealing requirements compared to one used for hydraulic oil or high-temperature fluids. Stainless steel and brass are commonly used for their corrosion resistance and mechanical strength, especially in demanding industrial environments.

Speed of rotation is another critical factor. A fluid rotary union operating at high speeds must be carefully matched with precision bearings and low-friction sealing technology to reduce wear and heat generation. Incorrect sizing can lead to excessive vibration, reduced efficiency, and premature failure.

Space limitations and installation requirements should also be considered when selecting a Through Bore Rotary Union. Compact designs are ideal for machines with limited installation space, while larger units are used in heavy-duty industrial systems where higher flow capacity is needed.

In conclusion, choosing the right rotary union through bore involves evaluating bore size, pressure rating, fluid type, rotational speed, and installation space. A properly selected hollow shaft rotary union or rotary joint through bore ensures smooth operation, reliable sealing, and long-term durability. By matching the correct specifications of a fluid rotary union to your application, you can significantly improve system efficiency and reduce maintenance costs.
